DOT R
A tool to light.
A luminaire designed for use with state-of-the-art LED modules to offer superior performance and a wide range of light beams.
Design Omar Carraglia - Davide Groppi / 2015
Model
DOT R
Type
Recessed
Use
Indoor
Finish
Matt White
Matt Black
CRI
>97
Input
Max 350mA DC
Power
13W
Material
Metal
Accessories
DRIVERS
1Z0240870.350
Driver
Input 220-240V(100-127V) - 50/60Hz - Output 350mA - 18W(15W) - IP20 - PUSH - 1-10V
OTHER ACCESSORIES
1A3090000.00.00
Lens
2700K - CRI >97 - 983lm - 14°
3000K - CRI >97 - 1038lm - 14°
3000K - CRI >97 - 1038lm - 14°
1A3100000.00.00
Lens
2700K - CRI >97 - 943lm - 24°
3000K - CRI >97 - 996lm - 24°
3000K - CRI >97 - 996lm - 24°
1A3110000.00.00
Lens
2700K - CRI >97 - 955lm - 36°
3000K - CRI >97 - 1005lm - 36°
3000K - CRI >97 - 1005lm - 36°
1A3120000.00.00
Lens
2700K - CRI >97 - 965lm - 50°
3000K - CRI >97 - 1016lm - 50°
3000K - CRI >97 - 1016lm - 50°
1X0080400.01.00
Accessory holder + Honeycomb louvre
1X0080000.02.00
Elliptical filter
Compulsory with 1X0080400.01.00
Standard
1X0080000.03.00
Blue filter
Compulsory with 1X0080400.01.00
Standard
1X0080000.04.00
Red filter
Compulsory with 1X0080400.01.00
Standard
1X0080000.05.00
Yellow filter
Compulsory with 1X0080400.01.00
Standard
